We provide supreme quality Hastelloy. It is imported from reliable vendors and is supplied to various parts of India. The Hastelloy that we provide is rich in different properties that make it an important component of various industrial applications. We are among the budding Hastelloy Suppliers in India.
Triton Alloys Inc are Manufacturers, Supplier and Exporters of Hastelloy C276 Buttweld Fittings that is Fabricated From High Quality Raw Materials. Hastelloy C276 Butt weld Fittings are Available in different forms and grades. We offer these products as per the international quality standards and are available at competitive prices.
HASTELLOY C-276 alloy is a nickel-molybdenum-chromium wrought alloy that is generally considered a versatile corrosion-resistance alloy. C-276 alloy is an improved wrought version of alloy C in that it usually doesn't need to be solution heat-treated after welding and has vastly improved fabricability. This alloy resists the formation of grain-boundary precipitaties in the weld heat-affected zone, thus making it suitable for most chemical process applications in the as-welded condition. However, in environments where attack of the C-276 alloy weld joint is experienced, C-22 weld filler materials should be considered.
Specification :
| Specifications | ASTM B366, ASME SB366 |
| size | Seamless Butt Weld Fittings: 1/2" - 10" |
| Welded Butt Weld Fittings: 1/2" - 48" | |
| Dimensions | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10 |
| Thickness | SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75 |
| Types | 90º Elbows, 45º Elbows, Tees, Crosses, Reducers, Pipe Cap, Stub End, Pipe Bend |
| DIN Standard Available | DN15-DN1200 |
| Elbow | Angle : 22.5 deg, 30deg, 45 deg, 90 deg, 180 deg, 1.0D, 1.5D, 2.0D, 2.5D, 3D, 4D, 5D, 6D, 7D-40D. |
| Standard: ASME B16.9, ASME B16.28, ASME B16.25, MSS SP-75 DIN2605 JISB2311 JISB2312 JISB2313, BS, GB, ISO | |
| Manufacturing process | Push, Press, Forge, Cast, etc. |
| Test Certificates | EN 10204/3.1B |
| Raw Materials Certificate | |
| 100% Radiography Test Report | |
| Third Party Inspection Report, etc | |
| Origin & Mills | Japanese, Indian, USA, Korean, European, Ukraine, Russian |
Hastelloy C276 Buttweld Fittings Equivalent Grades
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | OR | GOST |
| Hastelloy C276 | N10276 | 2.4819 | – | NiMo16Cr15W | NW 0276 | ЭП760 | ХН65МВУ |
Hastelloy C276 Buttweld Fittings Chemical Composition
| Hastelloy C276 | Ni | C | Mo | Mn | Si | Fe | P | S | Co | Cr |
| Balance | 0.01 max | 15 – 17 | 1.0 max | 0.08 max | 4 – 7 | 0.04 max | 0.03 max | 2.5 max | 14.5 – 16.5 |
Hastelloy C276 Buttweld Fittings Mechanical Properties
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 52,000 , MPa – 355 | Psi – 1,15,000 , MPa – 790 | 40 % |
Types of Buttweld Fittings Available
Long Radius Elbow
Short Radius
Long Radius Elbow
Short Radius Elbow
Long Radius Elbow
ASME B16.9 SS 180° Short Radius Elbow
1D Elbow
1.5D Elbow
3D Elbow
Seamless Buttwelding 180° Returns
Pipe Nipples
Lateral
Buttweld Fittings Applications Industries
ASME B16.9 Degree Forged are known to deliver exceptional performance and are generally developed for meeting the demands. We offer a broad range of Buttweld Fittings Degree Forged through a worldwide network of stock-keeping branches. Buttweld Forged is use in various industries like :
- Buttweld Fittings uses in Paper & Pulp Companies
- Stainless Steel Buttweld Fittings uses in Oil and Gas Industry
- Buttweld Fittings Pipe Forged uses in Chemical Refinery
- Alloy Steel Threaded Elbowuses in Pipeline
- Buttweld Buttweld Fittings Pipe Forged uses in High Temperature Application
- Buttweld Fittings uses in Water Pipe Line
- ANSI B16.9 Buttweld Fittings Pipe Forged can be used in Nuclear power plants
- Buttweld Fittings usefule for High Pressure Applications
- Buttweld Fittings Long Radius Forged uses in Fabrication and welding Job
- Buttweld Fittings uses in Food Processing and Dairy Industries
- Buttweld Fittings Short Radius Forged uses in boiler & heatexchangers
Marking & Packing
Our Nickel Alloy 2.4066 round bars are packaged to ensure that there is no damage during transit. In case of exports, standard export packaging is done in wooden cases. All Nickel Alloy UNS N02200 bar are marked with Grade, Lot No, Size and our trade mark. We can also make custom marking on our products on Special request from Purchaser.
Quality Assurance
Triton Alloys Inc all Nickel Alloy 200 round bars, Nickel Alloy 200 bright bars and Nickel 200 hex bars are subject to strict inspection at each stage starting from material purchasing to product dispatch. They are visually examined for conformity to ASTM, ASME, DIN, EN, and JIS codes and standards. We can also appoint official certified Inspection Agencies upon request of our clients so that they can witness the material reports, dimensions and quality conformity of products.
