Weldo Flanges, ASTM A182 Nipo Flanges, Stainless Steel Weldo Flanges, ANSI B16.5 Nipo Flanges, Steel Nipo Flanges Manufacturers, Carbon Steel Weldo Flanges, Steel Nipo Flanges Suppliers in India.
Manufacturer, stockist & supplier of Nipo Flange, Stainless Steel Flanges Slip-On | Weld Neck | Blind | Lap Joint | Socket Weld Flanges. Supplying ASTM A182 Weldo / Nipo Flange from approved manufactures and stockists based in the India.
Triton Alloys Inc produce & supply many different flange standards such as ASA/ANSI/ASME (USA), PN/DIN (European), BS10 (British/Australian), and JIS/KS (Japanese/Korean) & ASTM A182 Weldo / Nipo Flanges. To allow easy functionality and inter-changeability, these are designed to have standardised dimensions. The ANSI/ASME pressure classes for Flat-Face flanges are 125# and 250#. The classes for Ring-Joint, Tongue & Groove, and Raised-Face flanges are 150#, 300#, (400# – unusual), 600#, 900#, 1500#, and 2500#. At Triton Alloys Inc we stock a large inventory of ASME B16.5 or ASME B16.47 “industry standard” flanges for most piping applications. Triton Alloys Inc can produce Expander Flange according to the standards for materials, pressure ratings, etc. Such standards include DIN, BS, and/or ISO standards, Japanese JIS.
Specification :
| Size | ½” (15 NB) to 48″ (1200NB) |
| Standard | ANSI A182, ANSI B16.47, ANSI B16.36, ANSI B16.48, BS 4504, EN1092, UNI 2277/2278, DIN, JIS, SABS1123, GOST-12820 |
| Dimensions | ANSI A182, ANSI B16.47 Series A & B, MSS SP44, ASA, API-605, AWWA |
| Class | 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS, DIN Standard ND-6,10, 16, 25, 40 Etc. |
| Specialize | As per drawing |
| Connection Type | Ring Type Joint, Lap-Joint Face, Raised Face, Flat Face, Large Male-Female, Small Male-Female, Large |
| Form | SORF, WNRF, BLRF, SWRF, LAP Joint, Threaded, Reducing, Spectacle, etc |
| Stainless Steel | ASTM A-479, A-182, 304, 304L,304H,304S, 316, 316L,316 Ti, 316H, 309, 310, 310S, 317L, 321, 347, 409, 410, 420, 430, 440, 446, 904L. etc. |
| Duplex Steel | 2205, 31803, 32750, 32760, 2101, 2304. |
| Alloy Steel | A-182 - F5, F9, F11, F12, F21, F22 & F91 |
| Special Grade | Stainless Steel 17-4 PH, Alloy 800, Alloy 600. Hastelloy C276. |
| Carbon Steel | A 105, LF 2, Duplex Steel. |
| Test Certificate | MTC, IBR TC, Lab.TC from Govt. App. Lab. with Third Party Inspection. |
ASME B16.5 Nipoflange / Weldoflange Dimensions:
| Schedule STD | |||||
|---|---|---|---|---|---|
| Size | Size in mm | Height A | OD -B | Hole Dia C | Weight in KG |
| 1/4 | 8 | 14.3 | 25.4 | 15.9 | 0.04 |
| 3/8 | 10 | 19.05 | 31.75 | 19.05 | 0.07 |
| 1/2 | 15 | 19.05 | 34.93 | 23.81 | 0.08 |
| 3/4 | 20 | 22.23 | 44.45 | 30.16 | 0.11 |
| 1 | 25 | 26.99 | 53.98 | 36.51 | 0.23 |
| 1 1/4 | 32 | 31.75 | 65.09 | 44.45 | 0.36 |
| 1 1/2 | 40 | 33.34 | 73.03 | 50.8 | 0.45 |
| 2 | 50 | 38.1 | 88.9 | 65.09 | 0.79 |
| 2 1/2 | 65 | 41.28 | 103.19 | 76.2 | 1.13 |
| 3 | 80 | 44.45 | 122.24 | 93.66 | 1.81 |
| 3 1/2 | 90 | 47.63 | 142.88 | 112.71 | 2.5 |
| 4 | 100 | 50.8 | 152.4 | 120.65 | 2.86 |
| 5 | 130 | 57.15 | 179.3 | 141.29 | 4.65 |
| 6 | 150 | 60.33 | 215.9 | 169.86 | 6.44 |
| 8 | 200 | 69.85 | 263.53 | 220.66 | 10.66 |
| 10 | 250 | 77.79 | 322.26 | 274.64 | 17.69 |
| 12 | 300 | 85.73 | 377.83 | 325.44 | 26.76 |
| 14 | 350 | 88.9 | 409.58 | 357.19 | 29.94 |
| 16 | 400 | 93.6 | 463.55 | 407.99 | 34.02 |
| 18 | 450 | 96.84 | 520.7 | 458.79 | 44 |
| 20 | 500 | 101.6 | 571.5 | 508 | 53.52 |
| 24 | 600 | 144.5 | 717.5 | 609.6 | 101 |
| 26 | 650 | 155.6 | 778 | 660.4 | 120 |
| 30 | 750 | 174.6 | 893.6 | 762 | 190 |
| 36 | 900 | 206.4 | 1070 | 914.4 | 310 |
| 40 | 1000 | 225.4 | 1187.6 | 1016 | 435 |
| 42 | 1050 | 235 | 1244.6 | 1066.8 | 540 |
| 48 | 1200 | 241.3 | 1404 | 1219.2 | 750 |
| Schedule XS | |||||
| Size | Size in mm | Height – A | OD – B | Hole Dia – C | Weight in KG |
| 1/4 | 8 | N/A | 25.4 | 15.88 | 0.05 |
| 3/8 | 10 | N/A | 31.75 | 19.05 | 0.07 |
| 1/2 | 15 | 19.05 | 34.93 | 23.81 | 0.09 |
| 3/4 | 20 | 22.23 | 44.45 | 30.16 | 0.14 |
| 1 | 25 | 26.99 | 53.98 | 36.51 | 0.21 |
| 1 1/4 | 32 | 31.75 | 65.09 | 44.45 | 0.41 |
| 1 1/2 | 40 | 33.34 | 73.03 | 50.8 | 0.5 |
| 2 | 50 | 38.1 | 88.9 | 65.09 | 0.79 |
| 2 1/2 | 65 | 41.28 | 103.19 | 76.2 | 1.18 |
| 3 | 80 | 44.45 | 122.24 | 93.66 | 1.86 |
| 3 1/2 | 90 | 47.63 | 136.53 | 112.71 | 2.54 |
| 4 | 100 | 50.8 | 152.4 | 120.65 | 2.9 |
| 6 | 150 | 77.79 | 225.43 | 169.86 | 10.43 |
| 8 | 200 | 98.43 | 292.1 | 220.66 | 16.78 |
| 10 | 250 | 93.66 | 323.85 | 265.11 | 20.87 |
| 12 | 300 | 103.1 | 379.41 | 317.5 | 27.67 |
| 14 | 350 | 100.01 | 431.8 | 350.84 | 31.75 |
| 16 | 400 | 106.36 | 466.73 | 403.23 | 46.27 |
| 18 | 450 | 111.13 | 523.88 | 455.61 | 58.97 |
| 20 | 500 | 119.06 | 582.61 | 509.59 | 71.67 |
| 24 | 600 | 152.4 | 722.2 | 609.6 | 142 |
| 26 | 650 | 165.1 | 782.6 | 660.4 | 168 |
| 30 | 750 | 181 | 896.8 | 762 | 218 |
| 36 | 900 | 212.7 | 1074.4 | 914.4 | 404 |
| 40 | 1000 | 235 | 1194 | 1016 | 582 |
| 42 | 1050 | 244.5 | 1250.8 | 1066.8 | 590 |
| 48 | 1200 | 273 | 1425.6 | 1219.2 | 910 |
| Schedule XXS | |||||
| Size | Size in mm | Height – A | OD – B | Hole Dia – C | Weight in KG |
| 1/2 | 15 | 28.58 | 34.93 | 14.29 | 0.11 |
| 3/4 | 20 | 31.75 | 44.45 | 19.05 | 0.32 |
| 1 | 25 | 38.1 | 50.8 | 25.4 | 0.38 |
| 1 1/4 | 32 | 44.45 | 61.91 | 33.34 | 0.57 |
| 1 1/2 | 40 | 50.8 | 69.85 | 38.1 | 0.79 |
| 2 | 50 | 55.56 | 80.96 | 42.86 | 0.97 |
| 2 1/2 | 65 | 61.91 | 96.84 | 53.98 | 1.53 |
| 3 | 80 | 73.03 | 120.65 | 73.03 | 2.87 |
| 4 | 100 | 84.14 | 152.4 | 98.43 | 4.76 |
| 5 | 130 | 93.66 | 187.33 | 122.24 | 6.46 |
| 6 | 150 | 104.78 | 220.66 | 146.05 | 12.7 |
| 8 | 200 | 111.12 | 284.16 | 173.04 | 20.41 |
| 10 | 250 | 125.41 | 312.74 | 215.9 | 38.56 |
| Schedule 160 | |||||
| Size | Size in mm | Height – A | OD – B | Hole Dia – C | Weight in KG |
| 1/2 | 15 | 28.58 | 34.93 | 14.29 | 0.11 |
| 3/4 | 20 | 31.75 | 44.45 | 19.05 | 0.32 |
| 1 | 25 | 38.1 | 50.8 | 25.4 | 0.38 |
| 1 1/4 | 32 | 44.45 | 61.91 | 33.34 | 0.57 |
| 1 1/2 | 40 | 50.8 | 69.85 | 38.1 | 0.79 |
| 2 | 50 | 55.56 | 80.96 | 42.86 | 0.97 |
| 2 1/2 | 65 | 61.91 | 96.84 | 53.98 | 1.53 |
| 3 | 80 | 73.03 | 120.65 | 73.03 | 2.87 |
| 4 | 100 | 84.14 | 152.4 | 98.43 | 4.76 |
| 5 | 130 | 93.66 | 187.33 | 122.24 | 6.46 |
| 6 | 150 | 104.78 | 220.66 | 146.05 | 12.7 |
| 8 | 200 | 111.12 | 284.16 | 173.04 | 20.41 |
| 10 | 250 | 125.41 | 312.74 | 215.9 | 38.56 |
Types of Flanges Available
Blind Flanges
Slip on Flanges
Socket Weld Flanges
Threaded Flanges
Weld Neck Flange
Lap Joint Flange
Expander Flange
Nippo Flanges
Reducing
Ring Type Joint Flanges
High Hub Flange
Square Flange
Flanges Applications Industries
ASME B16.9 Degree Forged are known to deliver exceptional performance and are generally developed for meeting the demands. We offer a broad range of Buttweld Degree Forged through a worldwide network of stock-keeping branches. Buttweld Forged is use in various industries like :
- Flanges uses in Paper & Pulp Companies
- Stainless Steel Flanges uses in Oil and Gas Industry
- Flanges Pipe Forged uses in Chemical Refinery
- Alloy Steel Threaded Elbowuses in Pipeline
- Buttweld Flanges Pipe Forged uses in High Temperature Application
- Flanges uses in Water Pipe Line
- ANSI B16.9 Flanges Pipe Forged can be used in Nuclear power plants
- Flanges usefule for High Pressure Applications
- Flanges Long Radius Forged uses in Fabrication and welding Job
- Flanges uses in Food Processing and Dairy Industries
- Flanges Short Radius Forged uses in boiler & heatexchangers
Marking & Packing
Our Nickel Alloy 2.4066 round bars are packaged to ensure that there is no damage during transit. In case of exports, standard export packaging is done in wooden cases. All Nickel Alloy UNS N02200 bar are marked with Grade, Lot No, Size and our trade mark. We can also make custom marking on our products on Special request from Purchaser.
Quality Assurance
Triton Alloys Inc all Nickel Alloy 200 round bars, Nickel Alloy 200 bright bars and Nickel 200 hex bars are subject to strict inspection at each stage starting from material purchasing to product dispatch. They are visually examined for conformity to ASTM, ASME, DIN, EN, and JIS codes and standards. We can also appoint official certified Inspection Agencies upon request of our clients so that they can witness the material reports, dimensions and quality conformity of products.
